The FarAmp Home Energy Storage System Series offers two installation options

Facebook
Twitter
LinkedIn

Description

• The FarAmp Home Energy Storage System Series offers two installation options, wall-mounted and floor-standing, and battery capacities of 50Ah, 100Ah, and 200Ah to flexibly meet household energy needs.

•The series uses A-grade lithium iron phosphate cells with a cycle life of over 6000 times, built-in BMS for safety protection, and supports RS485/RS232/CAN communication protocols.

•The system is compatible with various energy storage inverters on the market, catering to a diverse range of user needs.



▏Features



•High integration/high security;

•Strong environmental adaptability, IP20 protection;

•Quick deployment, easy installation, operation, and maintenance;

•System efficiency above 90%;

• Maximum system support continuous 1C operation;

•Support multi-machine parallel connection

•Distributed deployment is combined with centralized networking



▏General Specifications



Model FARAMP4850 FARAMP48100 FARAMP48200
Nominal energy(kwh) 2.56 5.12 10.24
Nominal voltage(kwh) 51.2V
Chemistry LiFePO4
Operating voltage range 40V-58.4V
Max discharge/discharge current 50A 100A 200A
ParallelsFunction Support
Communication interface RS485、RS232、CAN
Cycle life >6000Cycles
Operating temperature range Charging:0-55℃ Discharging:-20-55℃
Protection level IP20
Color white/customizable
Dimension 550×440×125 600×510×173 800×710×273
Weight 29kg 47kg 80kg
Installation Wall-mounted/Floor-type
